Saltley

Reference Section

Signal Number Plan

Saltley Signal Map (GIF Image)

Saltley Signal Map Classic Version (GIF Image) - Standard SimSig colour version; more printer friendly.

Saltley Signal Map (PDF File)

This is an Adobe Acrobat PDF files. If you don't have Adobe Acrobat Reader installed on your computer you can get a free download of the latest version from the Adobe website .

Signal Box Prefix Codes

Code	Box
BJ	Bearley Junction
DAW	Daw Mill GF
DY	Derby*
HA	Henley-in-Arden
HH	Hams Hall Control Centre*
KY	Kingsbury Shunt Frame*
LN	Leamington Spa*
NS	Birmingham New Street*
NW	Rugby SCC (Nuneaton to Water Orton)*
SH	Shirley
SJ	Stourbridge Junction*
TY	Tyseley No.1*
WH	Washwood Heath No.1 Shunt Frame
WL	Walsall*

*Fringe box, signals not controlled in this simulation.

Timetabling Details

Note that due to various layout changes since Saltley closed (including re-modelling at Stratford-Upon-Avon, Whitlocks End, Shirley, Tyseley/Small Heath, new platforms at Moor Street and a new loop at Alvechurch), modern-day timetables for this simulation are not feasible.

Splash Screens

Splash1	Washwood Heath on the real panel
Splash2	Lawley St/Landor St Junction on the real panel
Splash3	Bordesley Jn/Landor St Jn/Lawley St on the real panel

The SimSig team visited on a bank holiday, hence the '-WE- AINT OPEN' in the TD berths at Lawley Street.

Additional Information

SY8 is the Platform 4 down starter signal at Barnt Green station, and it is controlled by Saltley South Top Panel.

The signal is notorious for being the setting for an interesting conversation between the signaller at Saltley South Top panel and the driver of 2R43. The full conversation taken from the signal box recordings can be found on this YouTube video , and a thread about the whole incident is available here on the forum for any relevant discussions.
